6027R-120
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 36VA THRU HOLE
PDF
/
Inventory: 7909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 55.56mm
Length 66.68mm
Height Seated (Max) 39.67mm
Technical
VA Rating 36 VA
Number of Secondary Winding 2
Output Voltage 2 60V
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 60V
Power - Max 36VA
Current - Output (Max) Parallel 600mA Series 300mA
Max Output Current 300mA
Voltage - Isolation 2500Vrms
Physical Dimension L66.68XB55.56XH39.69 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 36W
Power Rating 36W
Additional Feature SINGLE 230V
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 66.68mm Lx55.55mm W
Series 6027R
Published 2010
Packaging Bulk
Physical
Weight 1.1lbs 499g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
