6027-056
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 36VA THRU HOLE
PDF
/
Inventory: 9628
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Packaging Bulk
Published 2010
Series 6027
Size / Dimension 66.68mm Lx55.55mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
Type Laminated Core
Power Rating 36W
Max Power Dissipation 36W
Termination Style PC Pin
Voltage - Isolation 2500Vrms
Max Output Current 1.3A
Current - Output (Max) Parallel 1.3A Series 650mA
Element Configuration Dual
Power - Max 36VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 28V Series 56V
Secondary Winding(s) Dual
Dimensions
Height Seated (Max) 39.67mm
Length 66.68mm
Width 55.55mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Physical
Weight 1.1lbs 499g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
