6027-048
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 36VA THRU HOLE
PDF
/
Inventory: 3124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 1.1lbs 499g
Technical
Packaging Bulk
Published 2010
Series 6027
Size / Dimension 66.68mm Lx55.55mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature SINGLE 230V
Power Rating 36W
Max Power Dissipation 36W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L66.68XB55.56XH39.69 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1.5A
Current - Output (Max) Parallel 1.5A Series 750mA
Power - Max 36VA
Output Voltage 1 24V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 24V Series 48V
Output Voltage 2 24V
Number of Secondary Winding 2
VA Rating 36 VA
Dimensions
Height Seated (Max) 39.67mm
Length 66.68mm
Width 55.56mm
Compliance
RoHS Status Non-RoHS Compliant
