6026-028
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 7103
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.8lb 362.87g
Technical
Packaging Bulk
Published 2010
Series 6026
Size / Dimension 57.15mm Lx47.63mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature SINGLE 230V
Power Rating 20W
Max Power Dissipation 20W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L57.15XB47.63XH36.51 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1.4A
Current - Output (Max) Parallel 1.4A Series 700mA
Power - Max 20VA
Output Voltage 1 14V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 14V Series 28V
Output Voltage 2 14V
Number of Secondary Winding 2
VA Rating 20 VA
Dimensions
Height Seated (Max) 36.50mm
Length 57.15mm
Width 47.63mm
Compliance
RoHS Status Non-RoHS Compliant
