6025R-048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 5093
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 39.69mm
Length 47.63mm
Height Seated (Max) 36.50mm
Technical
VA Rating 12 VA
Number of Secondary Winding 2
Output Voltage 2 24V
Voltage - Secondary (Full Load) Parallel 24V Series 48V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 24V
Power - Max 12VA
Current - Output (Max) Parallel 500mA Series 250mA
Max Output Current 250mA
Voltage - Isolation 2500Vrms
Physical Dimension L47.63XB39.69XH36.51 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 12W
Power Rating 12W
Additional Feature SINGLE 230V
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 47.63mm Lx39.67mm W
Series 6025R
Published 2010
Packaging Bulk
Physical
Weight 0.7lb 317.51g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
