6025R-024
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 6566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.7lb 317.51g
Technical
Packaging Bulk
Published 2010
Series 6025R
Size / Dimension 47.63mm Lx39.67mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Additional Feature SINGLE 230V
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L47.63XB39.69XH36.51 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1A
Current - Output (Max) Parallel 1A Series 500mA
Power - Max 12VA
Output Voltage 1 12V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Output Voltage 2 12V
Number of Secondary Winding 2
VA Rating 12 VA
Dimensions
Height Seated (Max) 36.50mm
Length 47.63mm
Width 39.69mm
Compliance
RoHS Status ROHS3 Compliant
