6025-036
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 3563
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Center Tap No
Voltage - Secondary (Full Load) Parallel 18V Series 36V
Output Voltage 2 18V
Number of Secondary Winding 2
VA Rating 12 VA
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 18V
Power - Max 12VA
Current - Output (Max) Parallel 700mA Series 350mA
Max Output Current 350mA
Voltage - Isolation 2500Vrms
Physical Dimension L47.63XB39.69XH36.51 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 12W
Power Rating 12W
Additional Feature SINGLE 230V
Terminal Finish Tin/Lead (Sn/Pb)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Size / Dimension 47.63mm Lx39.67mm W
Series 6025
Published 2010
Packaging Bulk
Dimensions
Height Seated (Max) 36.50mm
Length 47.63mm
Width 39.69mm
Compliance
RoHS Status Non-RoHS Compliant
Physical
Weight 0.7lb 317.51g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
