6023R-020
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.4VA THRU HOLE
PDF
/
Inventory: 5184
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 28.58mm
Length 34.93mm
Height Seated (Max) 30.15mm
Technical
VA Rating 2.4 VA
Number of Secondary Winding 2
Output Voltage 2 10V
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 10V
Power - Max 2.4VA
Current - Output (Max) Parallel 240mA Series 120mA
Max Output Current 120mA
Voltage - Isolation 2500Vrms
Physical Dimension L34.93XB28.58XH30.16 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 2.4W
Power Rating 2.4W
Additional Feature SINGLE 230V
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 34.93mm Lx28.58mm W
Series 6023R
Published 2010
Packaging Bulk
Physical
Weight 0.25lb 113.4g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
