6022R-012
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Inventory: 1932
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.17lb 77.11g
Technical
Packaging Bulk
Published 2010
Series 6022R
Size / Dimension 34.93mm Lx28.58mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Additional Feature SINGLE 230V
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L34.93XB28.58XH23.81 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 90mA
Current - Output (Max) Parallel 180mA Series 90mA
Power - Max 1.1VA
Output Voltage 1 6.3V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Output Voltage 2 6.3V
Number of Secondary Winding 2
VA Rating 1.1 VA
Dimensions
Height Seated (Max) 23.80mm
Length 34.93mm
Width 28.58mm
Compliance
RoHS Status ROHS3 Compliant
