6022-020
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 1.1VA THRU HOLE
PDF
/
Inventory: 8441
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature SINGLE 230V
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L34.93XB28.58XH23.81 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 55mA
Current - Output (Max) Parallel 110mA Series 55mA
Power - Max 1.1VA
Output Voltage 1 10V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Output Voltage 2 10V
Number of Secondary Winding 2
VA Rating 1.1 VA
Pbfree Code no
JESD-609 Code e0
Size / Dimension 34.93mm Lx28.58mm W
Series 6022
Published 2010
Packaging Bulk
Dimensions
Height Seated (Max) 23.80mm
Length 34.93mm
Width 28.58mm
Compliance
RoHS Status Non-RoHS Compliant
Physical
Weight 0.17lb 77.11g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
