RoHS
/
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 36VA THRU HOLE
PDF
/
Inventory: 3025
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Width 55.55mm
Length 66.68mm
Height Seated (Max) 39.67mm

Technical

Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 36VA
Element Configuration Single
Current - Output (Max) Parallel 600mA Series 300mA
Max Output Current 300mA
Voltage - Isolation 2500Vrms
Termination Style PC Pin
Max Power Dissipation 36W
Power Rating 36W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 66.68mm Lx55.55mm W
Series 6017
Published 2010
Packaging Bulk

Physical

Weight 1.1lbs 499g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 13 Weeks
