6016R-048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 2435
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.8lb 362.87g
Technical
Packaging Bulk
Published 2010
Series 6016R
Size / Dimension 57.15mm Lx47.63mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 20W
Max Power Dissipation 20W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L57.15XB47.63XH36.51 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 400mA
Current - Output (Max) Parallel 800mA Series 400mA
Power - Max 20VA
Output Voltage 1 24V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 24V Series 48V
Output Voltage 2 24V
Secondary Winding(s) Dual
VA Rating 20 VA
Dimensions
Height Seated (Max) 36.50mm
Length 57.15mm
Width 47.63mm
Compliance
RoHS Status ROHS3 Compliant
