RoHS
/
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 1781
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.8lb 362.87g

Technical

Packaging Bulk
Published 2010
Series 6016
Size / Dimension 57.15mm Lx47.63mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Power Rating 20W
Max Power Dissipation 20W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L57.15XB47.63XH36.51 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1.1A
Current - Output (Max) Parallel 1.1A Series 550mA
Power - Max 20VA
Output Voltage 1 18V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 18V Series 36V
Output Voltage 2 18V
Secondary Winding(s) Dual
VA Rating 20 VA

Dimensions

Height Seated (Max) 36.50mm
Length 57.15mm
Width 47.63mm

Compliance

RoHS Status Non-RoHS Compliant
