6016-024
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 6260
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 47.63mm
Length 57.15mm
Height Seated (Max) 36.50mm
Technical
VA Rating 20 VA
Secondary Winding(s) Dual
Output Voltage 2 12V
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 12V
Power - Max 20VA
Current - Output (Max) Parallel 1.6A Series 800mA
Max Output Current 1.6A
Voltage - Isolation 2500Vrms
Physical Dimension L57.15XB47.63XH36.51 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 20W
Power Rating 20W
Terminal Finish Tin/Lead (Sn/Pb)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Size / Dimension 57.15mm Lx47.63mm W
Series 6016
Published 2010
Packaging Bulk
Physical
Weight 0.8lb 362.87g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
