Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 3513
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.7lb 317.51g

Technical

Packaging Bulk
Published 2010
Series 6015
Size / Dimension 47.63mm Lx39.67mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L47.63XB39.69XH36.51 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 1.6A
Current - Output (Max) Parallel 1.6A Series 800mA
Power - Max 12VA
Output Voltage 1 8V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Output Voltage 2 8V
Secondary Winding(s) Dual
VA Rating 12 VA

Dimensions

Height Seated (Max) 36.50mm
Length 47.63mm
Width 39.69mm

Compliance

RoHS Status Non-RoHS Compliant
