Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Inventory: 8079
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 33.34mm
Length 41.28mm
Height Seated (Max) 33.32mm

Technical

VA Rating 6 VA
Secondary Winding(s) Dual
Output Voltage 2 5V
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 5V
Power - Max 6VA
Current - Output (Max) Parallel 1.2A Series 600mA
Max Output Current 1.2A
Voltage - Isolation 2500Vrms
Physical Dimension L41.28XB33.34XH33.34 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 6W
Power Rating 6W
Terminal Finish Tin/Lead (Sn/Pb)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Size / Dimension 41.28mm Lx33.32mm W
Series 6014
Published 2010
Packaging Bulk

Physical

Weight 0.44lb 199.58g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 13 Weeks
