RU4S-M-D24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Power Relays, Over 2 Amps
Description
RELAY GEN PURPOSE 4PDT 6A 24V
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.736
≥1 USD $10.736
≥10 USD $9.54536
≥100 USD $8.113864
≥500 USD $6.562679
Inventory: 170
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Silver (Ag), Gold (Au)
Mount Socket
Mounting Type Socketable
Number of Pins 14
Technical
Operating Temperature -55°C~60°C
Packaging Bulk
Published 2008
Series RU
Feature Lighted Indicator, Mechanical Indicator, Test Button
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Current Rating 6A
Termination Style Plug In
Voltage - Rated AC 250V
Approval Agency CE, CSA, TUV, cULus
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Throw Configuration 4PDT
Max Voltage Rating (DC) 30V
Contact Form 4PDT (4 Form C)
Relay Type General Purpose
Coil Resistance 605Ohm
Operate Time 20ms
Coil Voltage 24VDC
Coil Type Non Latching
Switching Voltage 250VAC 30VDC -Max
Coil Current 44.7mA
Must Operate Voltage 19.2VDC
Must Release Voltage 2.4VDC
Coil Voltage (DC) 24V
Dimensions
Height 35mm
Compliance
RoHS Status ROHS3 Compliant
