RR3B-UAC12V

IDEC
RoHS
RoHS RoHS compliant
Package /
Category Relays / Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE 3PDT 10A 12V
PDF
/
Buying Options
Total Price: USD $18.37
Unit Price: USD $18.3744
≥1 USD $18.3744
≥10 USD $16.33632
≥100 USD $13.885696
Inventory: 36
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Silver (Ag)
Mount Socket
Mounting Type Socketable
Number of Pins 11
Weight 82g

Technical

Operating Temperature -25°C~40°C
Packaging Bulk
Series RR
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Termination Style Plug In, Quick Connect - 0.187 (4.7mm)
Max Voltage Rating (AC) 120V
Max Current Rating 10A
Throw Configuration 3PDT
Max Voltage Rating (DC) 30V
Contact Form 3PDT (3 Form C)
Relay Type General Purpose
Coil Resistance 18Ohm
Operate Time 25ms
Coil Voltage 12VAC
Coil Type Non Latching
Switching Voltage 240VAC 30VDC -Max
Coil Current 210mA
Must Operate Voltage 9.6VAC
Must Release Voltage 3.6VAC
Coil Voltage (AC) 12V

Compliance

RoHS Status ROHS3 Compliant
