RR2P-UDC48V
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Power Relays, Over 2 Amps
Description
Active ROHS3Compliant DPDT (2Form C) General Purpose Power Relay 25ms -25C~40C 1.6kOhm 30mA
PDF
/
Buying Options
Total Price: USD $18.63
Unit Price: USD $18.6296
≥1 USD $18.6296
≥10 USD $17.69768
≥100 USD $14.903416
Inventory: 64
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Silver (Ag)
Mount Socket
Mounting Type Socketable
Number of Pins 8
Technical
Operating Temperature -25°C~40°C
Packaging Bulk
Series RR
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Style Plug In, 8 Pin (Octal)
Max Voltage Rating (AC) 120V
Max Current Rating 10A
Throw Configuration DPDT
Max Voltage Rating (DC) 30V
Contact Form DPDT (2 Form C)
Relay Type General Purpose
Coil Resistance 1.6kOhm
Operate Time 25ms
Coil Voltage 48VDC
Coil Type Non Latching
Switching Voltage 240VAC 30VDC -Max
Coil Current 30mA
Must Operate Voltage 38.4VDC
Must Release Voltage 4.8VDC
Coil Voltage (DC) 48V
Compliance
RoHS Status ROHS3 Compliant
