RH4B-ULDC24V
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Power Relays, Over 2 Amps
Description
RELAY GEN PURPOSE 4PDT 10A 24V
PDF
/
Buying Options
Total Price: USD $18.77
Unit Price: USD $18.7704
≥1 USD $18.7704
≥10 USD $17.8332
≥100 USD $15.0172
Inventory: 194
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Silver Cadmium Oxide (AgCdO)
Mount Socket
Mounting Type Socketable
Number of Pins 14
Weight 74g
Technical
Operating Temperature -25°C~70°C
Packaging Bulk
Published 2003
Series RH
Feature Lighted Indicator
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
ECCN Code EAR99
Current Rating 10A
Termination Style Plug In, Quick Connect - 0.187 (4.7mm)
Voltage - Rated AC 240V
Approval Agency CE, CSA, TUV, UL
Max Voltage Rating (AC) 110V
Max Current Rating 10A
Throw Configuration 4PDT
Max Voltage Rating (DC) 30V
Contact Form 4PDT (4 Form C)
Relay Type General Purpose
Coil Resistance 388Ohm
Operate Time 25ms
Coil Voltage 24VDC
Coil Type Non Latching
Switching Voltage 120VAC 28VDC -Max
Coil Current 62mA
Must Operate Voltage 19.2VDC
Must Release Voltage 2.4VDC
Coil Voltage (DC) 24V
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
