RH2B-ULDC12V
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Power Relays, Over 2 Amps
Description
RELAY GEN PURPOSE DPDT 10A 12V
PDF
/
Buying Options
Total Price: USD $14.32
Unit Price: USD $14.3176
≥1 USD $14.3176
≥10 USD $12.72744
≥100 USD $12.0912
≥500 USD $11.454784
≥1000 USD $10.818456
≥3000 USD $9.863885
Inventory: 195
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Coil Voltage (DC) 12V
Must Release Voltage 1.2VDC
Must Operate Voltage 9.6VDC
Coil Current 150mA
Switching Voltage 240VAC 30VDC -Max
Coil Type Non Latching
Coil Voltage 12VDC
Operate Time 20ms
Coil Resistance 40Ohm
Relay Type General Purpose
Contact Form DPDT (2 Form C)
Max Voltage Rating (DC) 30V
Throw Configuration DPDT
Max Current Rating 10A
Max Voltage Rating (AC) 110V
Approval Agency CE, CSA, TUV, UL
Voltage - Rated AC 240V
Termination Style Plug In, Quick Connect - 0.187 (4.7mm)
Current Rating 10A
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Lighted Indicator
Series RH
Published 2003
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Weight 37g
Number of Pins 8
Mounting Type Socketable
Mount Socket
Contact Material Silver Cadmium Oxide (AgCdO)
Supply Chain
Factory Lead Time 4 Weeks
