6609070-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filter 50Hz/60Hz 80A 480VAC Terminal Block Flange Mount
PDF
/
Buying Options
Total Price: USD $587.31
Unit Price: USD $587.312
≥1 USD $587.312
≥10 USD $567.06144
Inventory: 26
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 168mm
Height 168mm
Technical
Voltage - Rated AC (Phase to Phase) 480V
Voltage - Rated AC (Phase to Ground/Neutral) 277V
Frequency - Operating 50/60Hz
Filter Type Three Phase (Delta)
Current 80A
Max Current Rating 80A
Max Voltage Rating (AC) 480V
Leakage Current 620μA
Configuration Single Stage
Approval Agency UR
Voltage - Rated AC 277V
Termination Style Terminal Block
Frequency 60Hz
Current Rating 80A
Depth 141mm
Voltage - Rated DC 480V
Voltage - Rated 480V
Applications Regenerative Motor Drive
Min Operating Temperature -10°C
Max Operating Temperature 40°C
Termination Terminal Block
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series FCD
Published 2007
Packaging Box
Operating Temperature -10°C~40°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Flanges, Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 34 Weeks
