RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 20A CHASSIS MOUNT
PDF
/
Buying Options
Total Price: USD $38.24
Unit Price: USD $38.236
≥1 USD $38.236
≥10 USD $36.96176
≥100 USD $35.68723
≥500 USD $34.412576
≥1000 USD $31.548
Inventory: 388
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 38.7mm
Length 85.6mm
Height 85.6mm
Technical
Frequency - Operating 50/60Hz
Filter Type Three Phase (Wye)
Max Current Rating 20A
Max Voltage Rating (AC) 250V
Leakage Current 5.5mA
ELV Compliant
Configuration Single Stage
Physical Dimension L85.1XB52.5XH38.7 (mm)/L3.35XB2.07XH1.53 (inch)
Approval Agency CSA, UR, VDE
Voltage - Rated AC 440V
Termination Style Quick Connect
Frequency 5.06kHz
Current Rating 20A
Depth 52.5mm
Voltage - Rated DC 440V
Capacitance 100nF
Applications General Purpose
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AYO
Published 2003
Packaging Bulk
Operating Temperature -10°C~40°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount, Flanges, Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
