2-6609037-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filter 50Hz/60Hz 12A 250VAC Quick Connect Flange Mount
PDF
/
Buying Options
Total Price: USD $32.15
Unit Price: USD $32.148856
≥1 USD $32.148856
≥10 USD $30.329117
≥100 USD $28.612372
≥500 USD $26.992802
≥1000 USD $25.464908
Inventory: 1118
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 57.15mm
Length 126.2mm
Height 45.21mm
Technical
High Pot 1500 V
Frequency - Operating 50/60Hz
Filter Type Single Phase
Max Current Rating 12A
Max Voltage Rating (AC) 250V
Leakage Current 250μA
Inductance 7.88mH
Configuration Two Stage
Physical Dimension L113.28XB57.15XH45.21 (mm)/L4.46XB2.25XH1.78 (inch)
Approval Agency CSA, UR, VDE
Voltage - Rated AC 250V
Termination Style Quick Connect
Frequency 60Hz
Current Rating 12A
Depth 57.2mm
Voltage - Rated 250V
Applications General Purpose
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EP
Published 2008
Packaging Bulk
Operating Temperature -10°C~40°C
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount, Flanges
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 19 Weeks
