RSEL-20R5W
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filters Filter 250VAC 0.5A
PDF
/
Buying Options
Total Price: USD $9.64
Unit Price: USD $9.6448
≥1 USD $9.6448
≥10 USD $9.41864
≥100 USD $9.012256
≥500 USD $8.8088
Inventory: 68
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Chassis Mount, Flanges
Mounting Type Chassis Mount
Weight 58.000006g
Technical
Operating Temperature -25°C~85°C
Published 2008
Series RSEL
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Applications General Purpose
Current Rating 500mA
Frequency 60Hz
Termination Style Wire Leads
Voltage - Rated AC 250V
Approval Agency CSA, EN, UL
Physical Dimension L50.0XB45.0XH20.0 (mm)/L1.969XB1.772XH0.787 (inch)
Configuration Single Stage
Leakage Current 1mA
Max Voltage Rating (AC) 250V
Max Current Rating 500mA
Max Voltage Rating (DC) 250V
Filter Type Single Phase
Insulation Resistance-Min 100MOhm
Dimensions
Length 50mm
Width 45mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
