FMBD-B92A-0812

Schurter Inc.
RoHS
RoHS RoHS compliant
Package 0812
Category Filters / Power Line Filter Modules
Description SCHURTER FMBD-B92A-0812 Power Line Filter, Chassis, 520 VAC, 8 A, 3 Phase + Neutral Line, Screw
PDF
/
Buying Options
Total Price: USD $143.27
Unit Price: USD $143.2728
≥1 USD $143.2728
≥10 USD $131.579536
Inventory: 15
Minimum: 1
-
+

Technical Details

Compliance

Ratings IP20
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 115mm
Length 155mm
Height 80mm

Technical

Frequency - Operating 50/60Hz
Leakage Current (Max) 1mA
Filter Type Three Phase (Wye)
Max Current Rating 8A
Max Voltage Rating (AC) 520V
Inductance L1 - 2mH, L2 - 4μH
Configuration Two Stage
Approval Agency cURus, ENEC, VDE
Voltage - Rated AC 300V 520V
Termination Style Terminal Block
Number of Conductors 4
Frequency 300MHz
Current Rating 8A
Depth 145mm
Voltage - Rated DC 520V
Additional Feature INDUCTANCE 2 MILLIHENRY
Applications General Purpose
Terminal Finish Tin (Sn)
Termination Terminal Block
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
JESD-609 Code e3
Series FMBD NEO
Published 2012
Packaging Bulk
Operating Temperature -25°C~100°C

Physical

Weight 1.11992kg
Package / Case 0812
Mounting Type Chassis Mount
Mount Chassis Mount, Screw

Supply Chain

Factory Lead Time 15 Weeks
