FMBC-A91C-1610
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
SCHURTER FMBC-A91C-1610 Power Line Filter, Chassis, 480 VAC, 16 A, 3 Phase, Screw
PDF
/
Buying Options
Total Price: USD $151.2
Unit Price: USD $151.195965
≥1 USD $151.195965
≥10 USD $142.637712
≥100 USD $134.563875
≥500 USD $126.947055
≥1000 USD $119.761367
Inventory: 1291
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Weight 1.11493kg
Technical
Operating Temperature -25°C~100°C
Packaging Bulk
Published 2011
Series FMBC NEO
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Terminal Block
Applications General Purpose
Additional Feature INDUCTANCE 1.9 MILLIHENRY
Voltage - Rated DC 480V
Depth 45.5mm
Current Rating 16A
Frequency 60Hz
Termination Style Terminal Block
Voltage - Rated AC 480V 520V
Approval Agency cURus, ENEC, VDE
Physical Dimension L200.0XB45.5XH70.0 (mm)/L7.874XB1.791XH2.756 (inch)
Configuration Two Stage
Inductance L1 - 1.9mH, L2 - 10μH
Max Voltage Rating (AC) 480V
Max Current Rating 16A
Filter Type Three Phase (Delta)
Leakage Current (Max) 33mA
Frequency - Operating 50/60Hz
Dimensions
Height 70mm
Length 250mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
