5500.2032
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filters 1-STAGE STD 10A FMLB
PDF
/
Buying Options
Total Price: USD $40.52
Unit Price: USD $40.516094
≥1 USD $40.516094
≥200 USD $16.167051
≥500 USD $15.626136
≥1000 USD $15.359617
Inventory: 3454
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 45mm
Technical
High Pot 2700 V
Frequency - Operating 50/60Hz
Filter Type Single Phase
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Leakage Current 500μA
Inductance 820μH
Configuration Single Stage
Physical Dimension L50.0XB45.0XH28.6 (mm)/L1.969XB1.772XH1.126 (inch)
Approval Agency cURus, ENEC, VDE
Voltage - Rated AC 125V 250V
Termination Style Quick Connect
Frequency 60Hz
Current Rating 10A
Depth 75mm
Additional Feature INDUCTANCE 0.82 MILLIHENRY
Applications General Purpose
Terminal Finish TIN COPPER/TIN
Termination Quick Connect
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series FMLB-09
Packaging Bulk
Operating Temperature -25°C~100°C
Physical
Weight 121.99999g
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount, Flanges
Supply Chain
Factory Lead Time 15 Weeks
