FN420-2.5-13
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
FN 420 Tray Quick Connect General Purpose EMC/EMI Line Filter 2.5A 400Hz 83mm 3.4mH
PDF
/
Buying Options
Total Price: USD $16.44
Unit Price: USD $16.4384
≥1 USD $16.4384
≥10 USD $15.92272
≥100 USD $15.409152
≥500 USD $14.89554
≥1000 USD $13.376
Inventory: 280
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 83mm
Height 17mm
Technical
High Pot 1700 V
Frequency - Operating DC~400Hz
Filter Type Single Phase
Max Current Rating 2.5A
Max Voltage Rating (AC) 250V
Leakage Current 190μA
Inductance 3.4mH
Configuration Single Stage
Approval Agency CSA, ENEC, UR
Voltage - Rated AC 250V
Termination Style Quick Connect
Frequency 400Hz
Current Rating 2.5A
Depth 41mm
Additional Feature AMP FAST-ON CONNECTIONS
Applications General Purpose
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Series FN 420
Packaging Tray
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount, Flanges
