FN409-3-02
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description
SCHAFFNER FN409-3-02 FILTER, DC CONVERTER, 3A
PDF
/
Buying Options
Total Price: USD $21.45
Unit Price: USD $21.4456
≥1 USD $21.4456
≥10 USD $20.75656
≥100 USD $20.06473
≥500 USD $19.372954
≥1000 USD $18.018
Inventory: 63
Minimum: 1
-
+
Technical Details
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -40°C~100°C
Packaging Tray
Published 2008
Series FN 409
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Termination PCB
Applications General Purpose
Additional Feature LG-MAX; WD-MAX
HTS Code 8542.39.00.01
Capacitance 4.7pF
Voltage - Rated DC 75V
Terminal Form PIN/PEG
Number of Functions 1
Depth 27.9mm
Current Rating 3A
Pin Count 5
Termination Style PC Pins
JESD-30 Code R-XXMA-P5
Voltage - Rated AC 75V
Approval Agency SEMKO, UR
Lead Length 7.4mm
Configuration Two Stage
Inductance 2.9mH
Max Current Rating 3A
Analog IC - Other Type ANALOG CIRCUIT
Current 13A
Filter Type Single Phase
Dimensions
Height 11.7mm
Length 50.8mm
Width 50.8mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
