FN402B-6.5-02
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Male IEC Filter PCB Mount, Rated At 6.5A, 250 V ac Operating Frequency DC to 400Hz
PDF
/
Buying Options
Total Price: USD $14.97
Unit Price: USD $14.969686
≥1 USD $14.969686
≥200 USD $5.973695
≥400 USD $5.774134
≥1000 USD $5.675667
Inventory: 4387
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -25°C~100°C
Packaging Tray
Series FN 402
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PCB
Resistance 1MOhm
Applications General Purpose
Gender Male
Additional Feature MEDICAL VERSION
Capacitance 100nF
Voltage - Rated DC 250V
Depth 28mm
Current Rating 6.5A
Frequency 400Hz
Termination Style PC Pins
Voltage - Rated AC 250V
Approval Agency CSA, ENEC, UR
Physical Dimension L45.0XB28.0XH16.5 (mm)/L1.772XB1.102XH0.65 (inch)
Configuration Single Stage
Inductance 1mH
Max Voltage Rating (AC) 250V
Max Current Rating 6.5A
Filter Type Single Phase
Leakage Current (Max) 0.002mA
Frequency - Operating DC~400Hz
High Pot 2500 V
Dimensions
Height 16.5mm
Length 45mm
Width 45mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
