FN356-36-24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 36A CHASSIS MOUNT
PDF
/
Buying Options
Total Price: USD $319.05
Unit Price: USD $319.0528
≥1 USD $319.0528
Inventory: 71
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP20
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 105mm
Length 105mm
Height 80mm
Technical
High Pot 2000 V
Frequency - Operating DC~60Hz
Filter Type Three Phase (Wye)
Max Current Rating 36A
Max Voltage Rating (AC) 440V
Leakage Current 430μA
Inductance 950 μH
Configuration Single Stage
Physical Dimension L140.0XB105.0XH80.0 (mm)/L5.512XB4.134XH3.15 (inch)
Approval Agency CSA, ENEC, UR
Voltage - Rated AC 250V
Termination Style Threaded Post (M6)
Frequency 60Hz
Current Rating 36A
Depth 190.8mm
Voltage - Rated DC 250V
Capacitance 2μF
Applications General Purpose
Termination Quick Connect
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series FN 356
Published 2006
Packaging Tray
Operating Temperature -25°C~100°C
Physical
Weight 1.2kg
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount, Flanges
Supply Chain
Factory Lead Time 10 Weeks
