FN3258H-16-45
RoHS
RoHS compliant
RoHS compliantPackage 300
Category Filters / Power Line Filter Modules
Description
Filter;1-Stage;EMC/RFI;3-Phase;520/300VAC;16A;Panel Mount;FN3258 Series
PDF
/
Inventory: 9799
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP20
RoHS Status RoHS Compliant
Dimensions
Length 250mm
Height 70mm
Technical
Voltage - Rated AC (Phase to Phase) 520V
High Pot 2650 V
Frequency - Operating DC~60Hz
Leakage Current (Max) 33mA
Rated Voltage 520V
Filter Type Three Phase (Delta)
Max Current Rating 16A
Configuration Single Stage
Physical Dimension L220.0XB45.0XH70.0 (mm)/L8.661XB1.772XH2.756 (inch)
Approval Agency CSA, ENEC, UR
Voltage - Rated AC 300V
Termination Style Terminal Block
Frequency 60Hz
Current Rating 16A
Depth 45mm
Applications General Purpose
Termination Terminal Block
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Pbfree Code yes
Series FN 3258
Published 2008
Packaging Tray
Operating Temperature -25°C~100°C
Physical
Package / Case 300
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
