FN258-30-33
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 30A CHASSIS MOUNT
PDF
/
Buying Options
Total Price: USD $221.78
Unit Price: USD $221.7776
≥1 USD $221.7776
≥10 USD $214.13128
Inventory: 45
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Chassis, Chassis Mount, Flanges
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~100°C
Packaging Tray
Published 2008
Series FN 258
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) Not Applicable
Termination Terminal Block
Applications Inverters, Power Drive Systems
Capacitance 6.6μF
Voltage - Rated DC 480V
Depth 355mm
Current Rating 30A
Frequency 60Hz
Termination Style Terminal Block
Voltage - Rated AC 277V
Approval Agency CSA, ENEC, UR
Physical Dimension L305.0XB60.0XH150.0 (mm)/L12.008XB2.362XH5.906 (inch)
Configuration Two Stage
Inductance 2 mH
Leakage Current 25.8mA
Max Voltage Rating (AC) 480V
Max Current Rating 30A
Wire/Cable Gauge 6 AWG
Filter Type Three Phase (Delta)
Frequency - Operating DC~60Hz
High Pot 2100 V
Dimensions
Height 150mm
Length 60mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings IP20
