FN2090A-6-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filter 0Hz to 400Hz 6A 250VAC Solder Lug Chassis Mount
PDF
/
Buying Options
Total Price: USD $23.26
Unit Price: USD $23.2584
≥1 USD $23.2584
≥10 USD $22.50556
≥100 USD $21.00516
≥500 USD $19.536
Inventory: 733
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 49.8mm
Length 54mm
Height 30.3mm
Technical
High Pot 2000 V
Frequency - Operating DC~400Hz
Leakage Current (Max) 0.08mA
Filter Type Single Phase
Max Current Rating 6A
Max Voltage Rating (AC) 250V
Inductance 8mH
Configuration Two Stage
Physical Dimension L64.8XB49.8XH30.3 (mm)/L2.551XB1.961XH1.193 (inch)
Approval Agency CE, CSA, ENEC, UR
Voltage - Rated AC 110V 250V
Termination Style Quick Connect
Frequency 400Hz
Current Rating 6A
Depth 85mm
Voltage - Rated DC 250V
Capacitance 470nF
Applications Safety
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series FN 2090
Published 2008
Packaging Tray
Operating Temperature -20°C~100°C
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
