FN2080A-10-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filters 10A SAFETY FASTON GENERAL PURPOSE FLTR
PDF
/
Buying Options
Total Price: USD $36.15
Unit Price: USD $36.1504
≥1 USD $36.1504
Inventory: 99
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 156mm
Height 45.4mm
Technical
High Pot 1100 V
Frequency - Operating DC~400Hz
Filter Type Single Phase
Max Current Rating 10A
Leakage Current 74μA
Inductance 4.5mH
Configuration Two Stage
Physical Dimension L130.5XB56.0XH45.4 (mm)/L5.138XB2.205XH1.787 (inch)
Approval Agency CSA, ENEC, UR
Voltage - Rated AC 110V 250V
Termination Style Quick Connect
Frequency 400Hz
Current Rating 10A
Depth 57.5mm
Applications Safety
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series FN 2080
Published 2009
Packaging Tray
Operating Temperature -25°C~100°C
Physical
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
