FN2060-10-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 250VAC 10A CHASS MNT
PDF
/
Buying Options
Total Price: USD $48.21
Unit Price: USD $48.211001
≥1 USD $48.211001
≥200 USD $19.236611
≥500 USD $18.59329
≥1000 USD $18.276881
Inventory: 6974
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 54mm
Length 54mm
Height 40.3mm
Technical
High Pot 1100 V
Frequency - Operating DC~400Hz
Filter Type Single Phase
Wire/Cable Gauge 18 AWG
Max Current Rating 10A
Max Voltage Rating (AC) 250V
Leakage Current 400μA
Inductance 800μH
Configuration Two Stage
Physical Dimension L64.8XB49.8XH30.3 (mm)/L2.551XB1.961XH1.193 (inch)
Approval Agency CE, CSA, ENEC, UR
Voltage - Rated AC 250V
Termination Style Quick Connect
Frequency 400Hz
Current Rating 10A
Depth 85mm
Voltage - Rated DC 250V
Capacitance 470nF
Additional Feature INDUCTANCE 0.8 MILLIHENRY
Applications General Purpose
Resistance 470kOhm
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series FN 2060
Published 2003
Packaging Tray
Operating Temperature -25°C~100°C
Physical
Weight 190g
Mounting Type Chassis Mount
Mount Chassis, Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
