FN2030-3-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 250VAC 3A CHASS MNT
PDF
/
Buying Options
Total Price: USD $11.88
Unit Price: USD $11.88
≥1 USD $11.88
Inventory: 1060
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Chassis, Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~100°C
Packaging Tray
Published 2009
Series FN 2030
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
Resistance 1MOhm
Applications General Purpose
Additional Feature INDUCTANCE 14 MILLIHENRY
Capacitance 330nF
Voltage - Rated DC 250V
Depth 46.6mm
Current Rating 3A
Frequency 400Hz
Termination Style Quick Connect
Voltage - Rated AC 250V
Approval Agency CSA, ENEC, UR
Physical Dimension L50.5XB44.5XH22.3 (mm)/L1.988XB1.752XH0.878 (inch)
Configuration Single Stage
Inductance 14mH
Leakage Current 520μA
Max Voltage Rating (AC) 250V
Max Current Rating 3A
Wire/Cable Gauge 20 AWG
Filter Type Single Phase
Frequency - Operating DC~400Hz
High Pot 1100 V
Dimensions
Height 22.3mm
Length 71mm
Width 46.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
