FN2020-3-06
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 250VAC 3A CHASS MNT
PDF
/
Buying Options
Total Price: USD $16.02
Unit Price: USD $16.016
≥1 USD $16.016
≥10 USD $13.54848
≥100 USD $13.1384
≥500 USD $12.31721
≥1000 USD $11.08543
≥3000 USD $10.692
Inventory: 690
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 35mm
Length 43.5mm
Technical
High Pot 2000 V
Frequency - Operating DC~400Hz
Leakage Current (Max) 0.74mA
Filter Type Single Phase
Inductance 2.5mH
Configuration Single Stage
Physical Dimension L43.5XB32.5XH29.3 (mm)/L1.713XB1.28XH1.154 (inch)
Approval Agency CSA, ENEC, UR
Voltage - Rated AC 250V
Termination Style Quick Connect
Current Rating 3A
Voltage - Rated DC 250V
Capacitance 220nF
Additional Feature INDUCTANCE 2.5 MILLIHENRY
Applications General Purpose
Resistance 1MOhm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series FN 2020
Published 2003
Packaging Tray
Operating Temperature -25°C~100°C
Physical
Weight 80g
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
