B84113C0000B110
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description
Quick Connect SINGLE PHASE EMI FILTER UL; CSA; ENEC-10 TAB CONNECTORS ON FACE ENDS MOUNTING TABS ON FACE ENDS EMC/EMI Line Filter 500muA 60Hz 159mm 3.6mH
PDF
/
Buying Options
Total Price: USD $55.58
Unit Price: USD $55.5808
≥1 USD $55.5808
≥10 USD $53.726754
≥100 USD $51.874073
≥500 USD $51.4624
Inventory: 132
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 50.8mm
Length 159mm
Height 38.1mm
Technical
High Pot 2700 V
Current Rating (Max) 10A
Current - Leakage 500μA
Filter Type SINGLE PHASE EMI FILTER
Max Voltage Rating (AC) 250V
Inductance 3.6 mH
Physical Dimension L153XB50.8XH44.5 (mm)
Approval Agency UL; CSA; ENEC-10
Voltage - Rated AC 250V
Frequency 60Hz
Current Rating 10A
Reach Compliance Code unknown
Depth 50.8mm
Voltage - Rated DC 250V
Capacitance 470nF
Additional Feature TAB CONNECTORS ON FACE ENDS, MOUNTING TABS ON FACE ENDS
Termination Quick Connect
Physical
Mount Flanges
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
