75TDVST2 image
Favorite
75TDVST2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Filters / Power Line Filter Modules
Description 3-PHASE 480V 75A CHASSIS TERMINAL BLOCK-TERMINAL BLOCK
PDF
/
Inventory: 2654
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 18 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount

Technical

Operating Temperature -25°C~100°C
Packaging Box
Published 2008
Series TDV
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Terminal Block
Applications General Purpose
Voltage - Rated 480V
Reach Compliance Code unknown
Current Rating 75A
Frequency 60Hz
Termination Style Terminal Block
Voltage - Rated AC 480V
Approval Agency cURus, ENEC, SEMKO
Physical Dimension L242.0XB92.0XH137.0 (mm)/L9.528XB3.622XH5.394 (inch)
Configuration Single Stage
Inductance 450μH
Filter Type Three Phase (Delta)
Frequency - Operating 50/60Hz

Dimensions

Height 137mm
Length 242mm
Width 92mm

Compliance

RoHS Status ROHS3 Compliant
