20DSGG5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
LINE FILTER 115/250VAC 20A CHASS
PDF
/
Buying Options
Total Price: USD $18.48
Unit Price: USD $18.47509
≥1 USD $18.47509
≥10 USD $17.429336
≥100 USD $16.442763
≥500 USD $15.512043
≥1000 USD $14.634004
Inventory: 1134
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount, Flanges
Mounting Type Chassis Mount
Technical
Packaging Box
Published 2008
Series DS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Connector, Quick Connect
Applications General Purpose
Reach Compliance Code unknown
Current Rating 20A
Frequency 60Hz
Termination Style Quick Connect
Voltage - Rated AC 115V 250V
Approval Agency CSA, UR, VDE
Physical Dimension L130.5XB86.4XH39.1 (mm)/L5.138XB3.402XH1.539 (inch)
Configuration Two Stage
Inductance L1 - 30mH, L2 - 930μH
Max Voltage Rating (AC) 250V
Max Current Rating 20A
Filter Type Single Phase
Leakage Current (Max) 0.9mA
Frequency - Operating 50/60Hz
Dimensions
Height 39.1mm
Length 130.5mm
Width 86.4mm
Compliance
RoHS Status ROHS3 Compliant
