20DRGS5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
Power Line Filter 2-Stage 50Hz/60Hz 20A 250VAC Threaded Stud Flange Mount
PDF
/
Buying Options
Total Price: USD $31.06
Unit Price: USD $31.0552
≥1 USD $31.0552
≥10 USD $30.05017
≥100 USD $28.046885
≥500 USD $25.04194
≥1000 USD $24.794
Inventory: 51
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Chassis Mount, Flanges
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~100°C
Packaging Bulk
Published 2008
Series DR
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw, Stud
Applications General Purpose
Voltage - Rated 250V
Depth 105.1mm
Current Rating 20A
Frequency 60Hz
Termination Style Threaded Post (8-32)
Voltage - Rated AC 115V 250V
Approval Agency CSA, UR, VDE
Physical Dimension L130.5XB84.6XH38.6 (mm)/L5.138XB3.331XH1.52 (inch)
Configuration Two Stage
Inductance 1mH
Max Voltage Rating (AC) 250V
Max Current Rating 20A
Filter Type Single Phase
Leakage Current (Max) 0.45mA
Frequency - Operating 50/60Hz
Dimensions
Height 38.6mm
Length 130.5mm
Width 84.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
