20DBCS5B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
SINGLE 250V 20A CHASSIS SCREW-SCREW
PDF
/
Buying Options
Total Price: USD $15.25
Unit Price: USD $15.247597
≥1 USD $15.247597
≥10 USD $14.384525
≥100 USD $13.570306
≥500 USD $12.802167
≥1000 USD $12.077518
Inventory: 1824
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 51.82mm
Length 84.84mm
Height 29.97mm
Technical
High Pot 2250 V
Frequency - Operating 50/60Hz
Leakage Current (Max) 2mA
Filter Type Single Phase
Inductance 600μH
Configuration Single Stage
Physical Dimension L84.84XB51.82XH29.97 (mm)/L3.34XB2.04XH1.18 (inch)
Approval Agency CSA, UR, VDE
Voltage - Rated AC 115V 250V
Termination Style Threaded Post (8-32)
Frequency 60Hz
Current Rating 20A
Applications General Purpose
Termination Stud, Threaded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DB
Published 2008
Packaging Box
Operating Temperature -25°C~100°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 18 Weeks
