05DKDG3S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
SINGLE 250V 5A CHASSIS IEC N/A-LUG
PDF
/
Buying Options
Total Price: USD $27.62
Unit Price: USD $27.619477
≥1 USD $27.619477
≥180 USD $11.020483
≥480 USD $10.652871
≥1020 USD $10.470378
Inventory: 4490
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 51.8mm
Length 79.8mm
Height 32.8mm
Technical
High Pot 2250 V
Frequency - Operating 50/60Hz
Leakage Current (Max) 2mA
Filter Type Single Phase
Inductance 4.5mH
Configuration Single Stage
Physical Dimension L79.8XB51.8XH32.8 (mm)/L3.142XB2.039XH1.291 (inch)
Approval Agency CSA, UR, VDE
Voltage - Rated AC 115V 250V
Termination Style IEC 320-C14, Quick Connect
Current Rating 5A
Reach Compliance Code unknown
Applications General Purpose
Termination Connector, Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DK
Published 2008
Packaging Box
Operating Temperature -25°C~100°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 18 Weeks
