EAP-30-331-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Power Line Filter Modules
Description
EAP Box Terminal Block General Purpose EMC/EMI Line Filter 30A 60Hz Hz 85mm 330pF
PDF
/
Buying Options
Total Price: USD $73.7
Unit Price: USD $73.700954
≥1 USD $73.700954
≥200 USD $29.407647
≥500 USD $28.424285
≥1000 USD $27.938512
Inventory: 3537
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 85mm
Height 30mm
Technical
High Pot 2500 V
Filter Type Single Phase
Leakage Current 37.5μA
Configuration Single Stage
Operating Frequency 60Hz Hz
Physical Dimension L85.0XB39.0XH30.0 (mm)/L3.346XB1.535XH1.181 (inch)
Approval Agency cURus, VDE
Voltage - Rated AC 250V
Termination Style Terminal Block
Current Rating 30A
Reach Compliance Code unknown
Voltage - Rated DC 250V
Capacitance 330pF
Applications General Purpose
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series EAP
Published 2010
Packaging Box
Operating Temperature -40°C~85°C
Physical
Mounting Type DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
