62-ARL-030-5-11
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description
Power Line Filter Single Phase 50Hz/60Hz 3A 250VAC Quick Connect Flange Mount
PDF
/
Inventory: 1443
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -25°C~85°C
Packaging Tray
Published 2014
Series 62-AL
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Applications General Purpose
Additional Feature ADDITIONAL COMPONENT BLEED RESISTOR; INDUCTANCE 2.4 MILLI HENRY
Capacitance 3.3nF
Depth 40mm
Termination Style Quick Connect
Voltage - Rated AC 250V
Approval Agency CSA, TUV, UR
Configuration Single Stage
Inductance 2.4mH
Max Voltage Rating (AC) 250V
Max Current Rating 3A
Filter Type Single Phase
Rated Current 3A
Leakage Current (Max) 0.5mA
Frequency - Operating 50/60Hz
Insulation Resistance-Min 300MOhm
High Pot 1500 V
Dimensions
Length 57.6mm
Compliance
RoHS Status Non-RoHS Compliant
