62-AFL-030-3-11

API Technologies Corp
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description Power Line Filter Single Phase 50Hz/60Hz 3A 250VAC Quick Connect Flange Mount
PDF
/
Inventory: 3294
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Chassis Mount
Mounting Type Chassis Mount

Technical

Operating Temperature -25°C~85°C
Packaging Tray
Published 2015
Series 62-AL
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Applications General Purpose
Additional Feature INDUCTANCE 2.4 MILLI HENRY
Capacitance 2.2nF
Depth 40mm
Termination Style Quick Connect
Voltage - Rated AC 250V
Approval Agency CSA, TUV, UR
Physical Dimension L38.8XB24.0XH16.7 (mm)/L1.528XB0.945XH0.657 (inch)
Configuration Single Stage
Inductance 2.4mH
Max Voltage Rating (AC) 250V
Max Current Rating 3A
Filter Type Single Phase
Rated Current 3A
Leakage Current (Max) 0.35mA
Frequency - Operating 50/60Hz
Insulation Resistance-Min 300MOhm
High Pot 1500 V

Dimensions

Height 16.7mm
Length 57.6mm
Width 24mm

Compliance

RoHS Status Non-RoHS Compliant
