62-AFC-016-5-11
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description
Power Line Filter Single Phase 50Hz/60Hz 1.6A 250VAC Quick Connect Flange Mount
PDF
/
Inventory: 7282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Rated AC 250V
Approval Agency CSA, TUV, UR
Physical Dimension L38.8XB24.0XH16.7 (mm)/L1.528XB0.945XH0.657 (inch)
Configuration Single Stage
Inductance 6mH
Max Voltage Rating (AC) 250V
Max Current Rating 1.6A
Filter Type Single Phase
Leakage Current (Max) 0.5mA
Frequency - Operating 50/60Hz
Insulation Resistance-Min 300MOhm
High Pot 1500 V
Termination Style Quick Connect
Depth 40mm
Capacitance 3.3nF
Additional Feature INDUCTANCE 6 MILLI HENRY
Applications General Purpose
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series 62-AC
Packaging Tray
Operating Temperature -25°C~85°C
Dimensions
Height 16.7mm
Length 57.6mm
Width 24mm
Compliance
RoHS Status Non-RoHS Compliant
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
