PSJS0DH30
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
Power Entry Module EMI/RFI Filtered M 3 POS 250VAC 3A/Contact Switch/Fuse ST 1 Port
PDF
/
Buying Options
Total Price: USD $27.57
Unit Price: USD $27.5704
≥1 USD $27.5704
≥10 USD $24.14632
≥100 USD $23.103168
≥500 USD $22.357808
≥1000 USD $21.612536
≥3000 USD $20.420083
Inventory: 46
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 0.031 ~ 0.114 0.79mm ~ 2.90mm
Technical
Switch Features Switch On-Off
Fuse Holder, Drawer Fuse Holder, Twin Fused
Fuse Yes
Accomodates a Fuse Yes (Fuse Not Included)
Current - IEC 3A
Filter Type Filtered (EMI, RFI) - Commercial, Medical
Voltage - IEC 120VAC
Current - UL 3A
Voltage - UL 250VAC
Current 3A
Connector Style IEC 320-C14
Leakage Current 2μA
ELV Compliant
Panel Cutout Dimensions Rectangular - 26.92mm x 66.04mm
Approval Agency CSA, UL, VDE
Voltage - Rated AC 250V
Current Rating 3A
Min Operating Temperature -10°C
Max Operating Temperature 40°C
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect - 0.187 (4.7mm)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series P, Corcom
Published 2001
Packaging Bulk
Physical
Number of Pins 3
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Snap in
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 25 Weeks
